DEPECHE MODE LIVE: A SPECTACULAR SHOW, A TECHNICAL NIGHTMARE
[From Bong 10, July 1990. Words: Jonathan Roberts.]
A World Violation tour technician describes the technical work involved in putting on each show - a real eye opener.
When you go to see a Depeche Mode concert, what are you actually listening to? A singer, three keyboard players and a tape machine? True enough, but you are hearing the end product of months of hard work, which will have started long before the tour got underway.
The huge amount of equipment that the boys use to record their albums would be impossible to carry around the world on tour, so they rely largely on samplers. A sampler (in Depeche Mode’s case, an E-Max II Turbo) digitally records the sounds that the band want to use, and allows Alan, Mart and Fletch to play them back in a concert situation. If you’ve watched the ‘101’ video then you will have heard Alan describe how the sounds are spread across the sampler keyboard enabling him to play ‘Black Celebration’, and the same principles apply to the rest of the songs.
On the current WORLD VIOLATION tour, there are two keyboards in front of each member of the band, but only one of these should ever be in use. This is because the second instrument is there as a backup to the main one in case it should fail. The second device is actually controlled by the first to ensure that they both create the same sounds.
Mart and Fletch also play electronic percussion pads. The action of hitting a pad ‘triggers’ samples on an extra E-Max II, which is kept under the stage for convenience, and to avoid clutter. This arrangement allows the boys to give a more dramatic presentation of songs like ‘Everything Counts’ and ‘Master and Servant’ because they can hit out at the drum pads rather than stand behind a keyboard.
Alan plays percussion too. For this tour we have had a special pair of tom toms built, which have been modified to allow Alan to trigger the sounds on the dedicated percussion E-Max ii as well as to play the drums themselves. Alan’s main keyboard is programmed to select the sounds created by the percussion keyboard which you hear when he hits the drums.
The tape machines that have backed Depeche Mode since they started have undergone as many changes as their keyboard rigs. On the WORLD VIOLATION tour we are using two Tascam MR16’s and of course the obligatory computer. Two sixteen track tape recorders on tour? Well yes: again there is a main machine and a backup. When you’re playing a concert to over 50,000 people, you can’t stop the show just because a tape won’t play, so we run the two at the same time. The computer keeps both machines perfectly synchronised, so that if the main machine stops or breaks for any reason then it can swap automatically to the other and the show can continue without so much as a hiccup.
So as you can see, the Depeche Mode set-up is a vastly complicated network of interlinked musical computers used to recreate their songs in a live situation, perfectly every time. It takes several months beforehand to program everything up and make the machines communicate correctly, and two full-time technicians, of which I am one, and Daryl is the other, to look after the equipment on the road.
This is state of the art musical technology employed by a great band as the best way to bring their music live to their fans. That’s why the show sounds so good!
